Mainboard|ASROCK|AMD B850|SAM5|Micro-ATX|Memory DDR5|Memory slots 2|1xPCI-Express 4.0 1x|2xPCI-Express 4.0 16x|1xM.2|1xHDMI|1xDisplayPort|1xAudio-In|1xAudio-Out|1xMicrophone|2xUSB 2.0|3xUSB 3.2|1xUSB-C|1xRJ45|B850M-XWIFI

129,89

X Series motherboard offers a compact, high-value solution, balancing performance, versatility, and reliability for both professional and daily tasks. Supports AMD Socket AM5 Ryzen™ 9000, 8000 and 7000 Series Processors 6+1+1 Phase Power Design, Dr.MOS for VCore 2 x DDR5 DIMMs Supports Dual Channel, up to 8200+ (OC) 2 PCIe 4.0 x16, 1 PCIe 4.0…

Out of stock

SKU: 1433281
Category:

Description

X Series motherboard offers a compact, high-value solution, balancing performance, versatility, and reliability for both professional and daily tasks.

Supports AMD Socket AM5 Ryzen™ 9000, 8000 and 7000 Series Processors

6+1+1 Phase Power Design, Dr.MOS for VCore

2 x DDR5 DIMMs

Supports Dual Channel, up to 8200+ (OC)

2 PCIe 4.0 x16, 1 PCIe 4.0 x1

Graphics Output Options: 1 HDMI, 1 DisplayPort

Realtek ALC897 7.1 CH HD Audio Codec, Nahimic Audio

1 Blazing M.2 (PCIe Gen5x4)

1 Hyper M.2 (PCIe Gen4x4)

4 SATA3

2 USB 3.2 Gen1 Type-C (1 Rear, 1 Front)

5 USB 3.2 Gen1 (3 Rear, 2 Front)

6 USB 2.0 (2 Rear, 4 Front)

Realtek 2.5G LAN

802.11axe WiFi 6E +Bluetooth

Supports BIOS Flashback

Additional information

Model

Chipset

Socket

Form Factor

Memory type

Frequency speed

Memory slots

PCI-Express 4.0 16x

M.2

PCI-Express 4.0 1x

HDMI

USB 2.0

RJ45

Audio-Out

DisplayPort

Audio-In

USB-C

Microphone

USB 3.2

SATA

WiFi

Bluetooth

SATA 3.0

Integrated video

Integrated audio

Integrated LAN

RAID

TPM

Unit Box Width

Unit Box Length

Unit Box Height

Bränd
