ASUS AMD B850 SAM5 ATX Memory DDR5 PRIME B850-PLUS WIFI — emaplaat
ASUS AMD B850 SAM5 ATX Memory DDR5 PRIME B850-PLUS WIFI — emaplaat - Pilt 2
ASUS AMD B850 SAM5 ATX Memory DDR5 PRIME B850-PLUS WIFI — emaplaat - Pilt 3
ASUS AMD B850 SAM5 ATX Memory DDR5 PRIME B850-PLUS WIFI — emaplaat - Pilt 4
ASUS AMD B850 SAM5 ATX Memory DDR5 PRIME B850-PLUS WIFI — emaplaat - Pilt 5

ASUS AMD B850 SAM5 ATX Memory DDR5 PRIME B850-PLUS WIFI — emaplaat

213,63 €

Model: PRIME B850-PLUS WIFI · Number of M.2 (M) slots: 3 · PCI Express x16 (Gen 3.x) slots: 2

Laos — kohal 1-5 tööpäeva

3 laos

Maksa kolmes võrdses osas 3 x 71.21€

Tootekood: 1434705 Kategooria:

Kirjeldus

ASUS PRIME B850-PLUS WIFI. Processor manufacturer: AMD, Processor socket: Socket AM5, Compatible processor series: AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series. Supported memory types: DDR5-SDRAM, Maximum internal memory: 256 GB, Memory slots type: DIMM. Supported storage drive interfaces: M.2, SATA III, Supported storage drive types: HDD & SSD, RAID levels: 0, 1, 5, 10. Ethernet interface type: 2.5 Gigabit Ethernet, Top Wi-Fi standard: Wi-Fi 6E (802.11ax). Component for: PC, Motherboard form factor: ATX, Motherboard chipset family: AMD

PRIME 850-PLUS WIFI
ASUS Prime series motherboards are expertly engineered to unleash the full potential of AMD Ryzen™ 9000 series processors. The PRIME B850-PLUS WIFI motherboard provides users and PC DIY builders with a range of performance optimizations via intuitive software and firmware features. It’s designed to be Advanced AI PC-ready, offering the power and connectivity needed for demanding AI applications.
* CEC Tier II ready

Üldine

NameMB AMD B850 SAM5 ATX/PRIME B850-PLUS WIFI ASUS
ModelPRIME B850-PLUS WIFI

BIOS

BIOS typeUEFI AMI

Expansion slots

Number of M.2 (M) slots3
PCI Express x16 (Gen 3.x) slots2
PCI Express x16 (Gen 4.x) slots1

Features

Compatible operating systemsWindows 11, Windows 10 64-bit
Windows operating systems supportedWindows 10 x64, Windows 11
Motherboard chipset familyAMD
Component forPC
Motherboard chipsetAMD B850

Graphics

Parallel processing technology supportNot supported

Internal I/O

12V power connectorYes
Number of COM connectors1
Thunderbolt headers1
TPM connectorYes
EPS power connector (8-pin)Yes
Chassis intrusion connectorYes
Number of chassis fan connectors4
ATX Power connector (24-pin)Yes
Front panel audio connectorYes
S/PDIF out connectorYes
Number of SATA III connectors4
USB 3.2 Gen 1 (3.1 Gen 1) connectors2
USB 2.0 connectors3

Memory

Unbuffered memoryYes
Maximum internal memory256 GB
Supported memory clock speed (max)8000 MHz
ECC сompatibilityECC & Non-ECC
Memory slots typeDIMM
Number of memory slots4
Supported memory typesDDR5-SDRAM

Network

Bluetooth version5.3
BluetoothYes
Top Wi-Fi standardWi-Fi 6E (802.11ax)
Wi-FiYes
Ethernet LANYes

Other features

Weight1.05 kg

Rear panel I/O ports

Microphone inYes
DisplayPorts quantity1
HDMI ports quantity1
Ethernet LAN (RJ-45) ports1
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity3
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity2
USB 2.0 ports quantity2

Storage controllers

RAID levels0, 1, 5, 10
RAID supportYes
Number of HDDs supported4

Weight & dimensions

Height48 mm
Depth244 mm
Width305 mm
Garantii36 kuud
EAN4711387931509
Tootja koodPRIME B850-PLUS WIFI

Lisainfo

Kaal 1,81 kg
Mõõtmed 35,7 × 6,8 × 27,4 cm
Varv

Multicolour
Form

ATX
Kanaleid

7.1 channels, Dual-channel
Cpu

1, AMD, AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series, Socket AM5, Yes
Storage

7, HDD & SSD, M.2, SATA III
Gpu

No
Liides

2.5 Gigabit Ethernet
Mälu

256 Mbit
