Dahua salvesti XVR5232AN

2 055,67

Number of HDDs supported: 2 · Ethernet LAN data rates: 10,100,1000 Mbit/s · Ethernet LAN (RJ-45) ports: 1

Laos — kohal 1-5 tööpäeva

1 laos

Maksa kolmes võrdses osas 3 x 685.22€

Tootekood: 1458519 Kategooria:

Kirjeldus

Dahua Technology XVR5232AN-4KL-I3/T. Product colour: Black, Maximum video resolution: 3840 x 2160 pixels, Video compression formats: H.264, H.264+, H.265, H.265+. Video resolutions: 3840 x 2160,1920 x 1080,1280 x 720. Video input channels: 32 channels. Ethernet interface type: Fast Ethernet, Gigabit Ethernet, Supported network protocols: HTTP, HTTPS, TCP/IP, IPv4, IPv6, RTSP, UDP, NTP, DHCP, DNS, SMTP, UPnP, FTP, DDNS, SNMP, P2P, Ethernet LAN data rates: 10,100,1000 Mbit/s. Maximum HDD capacity: 16 TB

  • 32-channel two-way talk over coaxial cable allows for seamless communication between the camera, client and recorder
  • 12-channel AcuPick for analog channels which improves the efficiency of target retrieval
  • 12-channel perimeter protection for analog channels which supports tripwire and intrusion detection powered by AI
  • 6-channel face recognition for analog channels which supports face comparison
  • 32-channel SMD Plus for analog channels or 64-channel SMD by camera which allows the device to trigger accurate alarms for humans and vehicles
  • 32-channel AI Coding saves on storage and bandwidth while maintaining the details of targets in videos
  • Supports HDCVI, AHD, TVI, CVBS and IP video input
  • Supports up to 64-channel IP camera input and each channel can be up to 8 MP. The incoming bandwidth reaches 256 Mbps
  • Supports accessing Wi-Fi cameras, making it suitable for a wide range of scenes
  • Smart H.265+ and H.265 dual-stream video compression

Üldine

NameDVR 32CH HDCVI PENTABRID/XVR5232AN-4KL-I3/T DAHUA

Hard drive

Number of HDDs supported2

Network

Ethernet LAN data rates10,100,1000 Mbit/s
Supported network protocolsHTTP, HTTPS, TCP/IP, IPv4, IPv6, RTSP, UDP, NTP, DHCP, DNS, SMTP, UPnP, FTP, DDNS, SNMP, P2P
Ethernet LAN (RJ-45) ports1
Ethernet LANYes

Operational conditions

Operating relative humidity (H-H)10 - 90%
Operating temperature (T-T)-10 - 55 °C

Packaging content

Quick start guideYes

Performance

Dual stream supportYes
Multi-display modes1, 4, 8, 9, 36, 25, 16
Multi-display supportedYes
Operating system installedEmbedded LINUX
Playback modesGeneral, Instant, Tag, Event, Smart
USB connectivityYes
Video loss detectionYes
Video motion detectionYes
Backup functionYes
Audio formats supportedG.711 A-law, G.711u, PCM
Video compression formatsH.264, H.264+, H.265, H.265+

Ports & interfaces

RS-485 ports1
Video RCA outputs1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity1
USB 2.0 ports quantity1
VGA (D-Sub) output ports1
HDMI ports quantity1
BNC input ports32

Power

Power consumption (typical)32 W
DC voltage12 V
Power supply typeDC

Technical details

Compliance certificatesCE

Weight & dimensions

Weight2.38 kg
Height53 mm
Depth333.9 mm
Width375 mm
Garantii36 kuud
EAN6937552419872
Tootja koodXVR5232AN-4KL-I3/T

Lisainfo

Kaal 4,02 kg
Mõõtmed 45 × 14,5 × 42,5 cm
Kanaleid

1.0 channels, 32 channels

Liides

Fast Ethernet, Gigabit Ethernet, Yes

Storage

-20 – 60 °C, 16 TB, 1U

Resolutsioon

3840 x 2160 pixels, 3840 x 2160,1920 x 1080,1280 x 720

Varv

Black
