GIGABYTE UD850GM PG5 ICE? ATX PC 100 – 240 V — toiteplokk

108,23 €

100 – 240 V · 850 W

Laos — kohal 1-5 tööpäeva

100 laos

Maksa kolmes võrdses osas 3 x 36.08€

Tootekood: 1447819 Kategooria:

Kirjeldus

GIGABYTE UD850GM PG5 V2 ICE Power Supply Unit- PCIe Gen 5.1, 80 PLUS Gold, Fully Modular Design, 120mm Fan, ATX 3.1 compatible, UK Plug. Total power: 850 W, AC input voltage: 100 – 240 V, AC input frequency: 50/60 Hz. Motherboard power connector: 20+4 pin ATX, Motherboard power cable length: 61 cm, PCI Express power connectors (12+4 pin) cable length: 700 mm. Purpose: PC, Power supply unit (PSU) form factor: ATX, 80 PLUS certification: 80 PLUS Gold. Product colour: White, Cooling type: Active, Fan diameter: 12 cm. Width: 150 mm, Depth: 140 mm, Height: 86 mm

Ensure reliable and efficient power delivery with GIGABYTE power supplies. Designed for peak performance and durability, our PSUs offer stable and consistent energy to power your high-performance systems. With advanced protections and high-quality components, GIGABYTE power supplies provide the confidence you need for seamless, uninterrupted computing experiences.

  • Intel ATX 3.1 and PCIe Gen 5.1 ready
  • 80 PLUS Gold certified
  • Fully modular design
  • Powerful single +12V rail
  • Compact size
  • 100% Japanese capacitors
  • 120mm smart hydraulic bearing (HYB) fan
  • Optimized thermal solution
  • OVP/OPP/SCP/UVP/OCP/OTP protection

Üldine

NameCASE PSU ATX3.1 850W/GP-UD850GM PG5 ICE GIGABYTE

Design

On/off switchYes
Number of fans1 fan(s)
Fan diameter12 cm
Cooling typeActive

Packaging data

Package typeBox

Performance

Bearing technologyHYB
ATX version3.1
PurposePC
80 PLUS certification80 PLUS Gold

Ports & interfaces

Cabling typeFully-Modular
Number of EPS connectors2
PCI Express connectorYes
Floppy drive power connector1
PCI Express power cable length60 cm
PCI Express power connectors (12+4 pin)1
PCI Express power connectors (12+4 pin) cable length700 mm
PCI Express power connectors (6+2 pin)4
Peripheral (Molex) power connectors (4-pin)3
Number of SATA power connectors8
Motherboard power cable length61 cm
Motherboard power connector20+4 pin ATX

Power

Power protection featuresOver current, Over power, Over voltage, Overheating, Short circuit, Under voltage
Efficiency90%
Hold time16 ms
Max output current (+5Vsb)3 A
Max output current (-12V)0.3 A
Max output current (+5V)20 A
Max output current (+12V)70.8 A
Max output current (+3.3V)20 A
Combined power (+5Vsb)15 W
Combined power (-12V)3.6 W
Combined power (+5V)105 W
Combined power (+12V)850 W
Combined power (+3.3V)105 W
Power Factor Correction (PFC) typeActive
Power factor0.9
Input current12 - 6.5 A
AC input frequency50/60 Hz
AC input voltage100 - 240 V
Total power850 W

Weight & dimensions

Weight2.4 kg
Height86 mm
Depth140 mm
Width150 mm
Garantii36 kuud
EAN4719331556495
Tootja koodGP-UD850GM PG5 ICE

Lisainfo

Kaal 2,62 kg
Mõõtmed 25,4 × 21,2 × 11,8 cm
Cpu

65 cm, Yes

Form

ATX

Varv

White

Mudel

UD850GM PG5 V2 ICE Power Supply Unit- PCIe Gen 5.1, 80 PLUS Gold, Fully Modular Design, 120mm Fan, ATX 3.1 compatible, UK Plug
